Sinoboom AB16EJ (AB520EJ)
Hires › Cherry Pickers / Boom Lifts › Sinoboom AB16EJ (AB520EJ)

Sinoboom AB16EJ (AB520EJ)

Sinoboom AB16EJ (AB520EJ)

Specification

Make
Make
Sinoboom
Model
Model
AB520EJ
Working Height
Working Height
17.7m / 58ft 1in
Platform Height
Platform Height
15.7m / 51ft 7in
Maximum Outreach
Maximum Outreach
9.3m / 30ft 7in
Min Weight
Min Weight
7,300.00kg / 16,133lbs
Safe Working Load
Safe Working Load
230.00kg / 508lbs
Machine Length
Machine Length
6.8m / 22ft 4in
Machine Width
Machine Width
1.9m / 6ft 3in
Machine Height
Machine Height
2m / 6ft 7in
Power Options
Power Options
Electric/Battery
Turning Radius
Turning Radius
0.7m / 2ft 4in
Gradeability
Gradeability
30%
Cage Rotation
Cage Rotation
160 degrees

Interested in hiring a Sinoboom AB16EJ (AB520EJ)?

ENQUIRE arrow icon Phone 0800 865 4455 Download Specification Download Specification
Overview Key Features Accessories Ideal Applications Resources

Sinoboom AB16EJ (AB520EJ) Electric Cherry Picker

The Sinoboom AB16EJ Electric Cherry Picker - also known as the AB520EJ - is a fantastic addition to our Electric MEWP fleet. With a working height of 17.7m, a platform capacity of 230kg, 30% gradeability and an incredible green performance, the Sinoboom AB16EJ will make a fabulous addition to any sustainable site, especially when working indoors.

Key features of the Sinoboom AB16EJ

  • Fully Electric, silent, zero emissions, long battery life
  • Narrow body of 1.9m, 50mm tail sweep almost zero
  • Smart screen display, fault and status information display for machine status and fault diagnosis, parameters and settings
  • Large tilt angle up to 5 degrees
  • 3 joysticks with variable proportional control, boom swing
  • Platform hydraulic levelling
  • Overload sensing system
  • 355° Turntable rotation
  • Platform 160° hydraulic rotation
  • Main boom gravitational lowering
  • Emergency brake release
  • Drive enable system
  • Display screen
  • Foam-filled tyres
  • Full proportional handle variant control
  • Fault diagnosis system
  • IOT-based operation monitoring
  • Horn and buzzer alarms
  • Emergency stop system
  • Lead-acid battery
  • Rotating warning lamp
  • Emergency lowering system
  • Rexroth pump system
  • Tilt protection
  • Tilt angle up to 5°

Recommended training course for this platform: IPAF Category: Mobile Boom (3b)

Available to hire, lease or buy from Hire Safe Solutions in the UK & ROI.

Call us on 0800 865 4455 for more information

Or, fill out an enquiry form here and we will get back to you as soon as possible.

Looking for something else?

Discover our entire range of Cherry Pickers/Boom Lifts here.

  • Construction Sites: Perfect for accessing elevated work areas on construction sites, including building maintenance, installation, and repair tasks.
  • Industrial Facilities: Ideal for industrial applications such as warehouse maintenance, equipment servicing, and facility inspections.
  • Event Management: Well-suited for event setup and maintenance tasks, including lighting, signage, and rigging installations.
  • Utility Work: Versatile enough to handle utility maintenance, tree trimming, and outdoor landscaping projects with ease.

The Sinoboom AB16EJ (AB520EJ) can be fitted-out with an assortment of accessories to increase productivity and safety on site.

Boom Lift Pipe Racks

Boom Lift Pipe Racks
Ground Guards

Ground Guards
Harness

Harness
Telematics

Telematics
Tool Tethers

Tool Tethers
Transformer & Lead

Transformer & Lead

The Sinoboom AB16EJ (AB520EJ) comes equipped with various features designed to enhance your efficiency and performance on the job.

Electric Powered

Electric Powered
Non-Marking Rough Terrain Tyres

Non-Marking Rough Terrain Tyres
Power to Platform

Power to Platform
