Dingli 2825 RT
Hires › Super MEWPs › Dingli 2825 RT

Dingli 2825 RT

Dingli 2825 RT

Specification

Make
Make
Dingli
Model
Model
2825 RT
Working Height
Working Height
28m / 91ft 11in
Platform Height
Platform Height
26m / 85ft 4in
Min Weight
Min Weight
19,800.00kg / 43,758lbs
Safe Working Load
Safe Working Load
1,000.00kg / 2,210lbs
Machine Length
Machine Length
5.96m / 19ft 7in
Machine Width
Machine Width
2.5m / 8ft 3in
Machine Height
Machine Height
4.13m / 13ft 7in
Power Options
Power Options
Diesel
Turning Radius
Turning Radius
3.5m / 11ft 6in
Gradeability
Gradeability
40%

Interested in hiring a Dingli 2825 RT?

ENQUIRE arrow icon Phone 0800 865 4455 Download Specification Download Specification
Overview Key Features Accessories Ideal Applications Resources

Dingli 2825 RT Diesel Scissor Lift

Capable of reaching a maximum height of 28m with a maximum load capacity of 1000kg, the Dingli 2825 RT offers outstanding versatility and sturdiness. The Dingli 2825 RT boasts a spacious 5.48 by 2.45m working platform, complete with a one-button extension deck that can reach up to 2.1m, allowing for up to 4 workers to operate conveniently, efficiently, and safely. With a gradeability of 40% and 4x4 drive and steering, the Dingli 2825 RT is the perfect machine for navigating challenging landscapes and working in tough conditions.

Key Features of the Dingli 2825 RT

  • Drivable At Full Height
  • Maximum of 4 people on platform
  • Outrigger legs
  • Proportional Joystick Controls
  • Self-Locking Gates
  • Automatic One-Way Platform Extension Deck
  • Four-Wheel Drive
  • Four-Wheel Steering
  • Automatic Braking System
  • Self-Weight Lowering System
  • Tubing Explosion-Proof System
  • Onboard Fault Diagnostic System
  • Tilt Alarm
  • Motion Alarm
  • Hydraulic Oil Cooling System
  • Flashing LED Beacon
  • Foldable Guard Rails
  • Drive Enable
  • Manual Brake Release
  • Lanyard Attachment Point
  • Tie-Down And Lifting Points
  • Automatic Levelling Hydraulic Outriggers
  • Anti-Restart Engine Protection
  • Emergency Pump
  • Emergency Stop Button
  • Platform Load Sense System

Recommended training course for this platform: IPAF Category: Mobile Vertical (3a)

Available to hire, lease or buy from Hire Safe Solutions in the UK & ROI.

Call us on 0800 865 4455 for more information

Or, fill out an enquiry form here and we will get back to you as soon as possible.

Looking for something else?

Discover our entire range of Scissor Lifts here.

  • General construction
  • Cladding
  • Architectural glazing
  • General building maintenance
  • Warehousing
  • Logistics Hubs

The Dingli 2825 RT can be fitted-out with an assortment of accessories to increase productivity and safety on site.

Chalwyn Valves

Chalwyn Valves
Ground Guards

Ground Guards
Large Scissor Pipe Racks

Large Scissor Pipe Racks
Nappies

Nappies
Spark Arrestors

Spark Arrestors
Telematics

Telematics
Tool Tethers

Tool Tethers
Wheel Covers

Wheel Covers
Outrigger Pads

Outrigger Pads

The Dingli 2825 RT comes equipped with various features designed to enhance your efficiency and performance on the job.

Diesel Powered

Diesel Powered
Rough Terrain Tyres - SL

Rough Terrain Tyres - SL
Self-Levelling Jacks

Self-Levelling Jacks
Four Wheel Drive

Four Wheel Drive
Four-Wheel Steering - SL

Four-Wheel Steering - SL
Crab Steering - SL

Crab Steering - SL
Large Scissor Single Deck Extension

Large Scissor Single Deck Extension
